Description
Highlight
- Measurement of air velocity, volume flow and temperature
- Display of the volume flow of multiple outlets in order to adjust systems
- Easy parametrization of the outlet (dimension and geometry)
- Convenient viewing of readings on a smartphone/tablet with the testo Smart Probes App
Description
Product Description
It fits perfectly into any shirt pocket: the testo 410i vane anemometer is ideal for measuring air velocity and temperature at air outlets and ventilation grilles. Even measuring and adjusting the volume flow is easy. The testo 410i gives you huge flexibility, so you can adapt to any unplanned measuring requirements in your everyday work.
Measuring convenience thanks to the App
The testo 410i combines professional Testo measuring technology with the efficient functions of an App. Your smartphone or tablet is used as a convenient display for your measuring values on site. You can view all measurement data via the testo Smart Probes App, and email the log immediately as a PDF or Excel file.
Configuration of the volume flow measurement is really easy with the App, partly due to the fact that you can carry out parametrization of the outlet (dimension, geometry) intuitively. Particularly useful: when adjusting a ventilation system, volume flows of multiple outlets can be cross-checked and compared. Timed and multi-point mean calculation also gives you a quick indication of the average air velocity, for example at a ventilation grille.
System requirements:
- iOS 11 or later
- Android 6.0 or later
- Bluetooth 4.0
Delivery Scope
testo 410i vane anemometer with smartphone operation, including protective cap, batteries and calibration protocol.
Specification
| Temperature - NTC |
|
Measuring range
|
-20 to +60 °C
|
|
Accuracy
|
±0.5 °C
|
|
Resolution
|
0.1 °C
|
| Velocity - Vane |
|
Measuring range
|
0.4 to 30 m/s
|
|
Accuracy
|
±(0.2 m/s + 2 % of mv) (0.4 to 20 m/s)
|
|
Resolution
|
0.1 m/s
|
| General technical data |
|
Weight
|
117.8 g
|
|
Dimensions
|
154 x 43 x 21 mm
|
|
Operating temperature
|
-20 to +50 °C
|
|
Product-/housing material
|
Plastic
|
|
System requirements
|
requires iOS 8.3 or newer; requires Android 4.3 or newer; requires mobile end device with Bluetooth 4.0
|
|
Product colour
|
black/orange
|
|
Battery type
|
3 AAA micro batteries
|
|
Battery life
|
130 h
|
|
Diameter vane
|
30 mm
|
|
Storage temperature
|
-20 to +60 °C
|
Applications
The compact vane anemometer testo 410i, in combination with a smartphone or tablet, is suitable for measuring air flow velocity, volume flow and temperature at air outlets, and for regulating the air flow of a ventilation system. Via the testo Smart App installed on the end device, users can comfortably read off their measurement values, configure volume flow measurements quickly and easily, and reliably determine timed and multi-point mean values. Especially useful: when regulating a ventilation system, you can compare the volume flows of several outlets. The measurement protocols can then be directly sent as PDF or Excel files.
Download
Product Brochure
What's in the box
testo 410i vane anemometer with smartphone operation, including protective cap, batteries and calibration protocol.
